Products Description
The molecule is equipped with three types of active groups:
1. Acrylic double bond: UV light-cured free radical crosslinking;
2. Secondary hydroxyl group: Can undergo secondary crosslinking with isocyanates and acid anhydrides, enhancing adhesion;
3. Phenolic oxygen-containing aromatic ring structure: High refractive index, low dielectric loss, strong temperature resistance, improving resin rigidity and weather resistance.
2-Hydroxy-3-Phenoxypropyl Acrylate (HPPA, CAS 16969-10-1) is a multifunctional acrylate monomer with acrylate double bond, reactive hydroxyl group and phenoxy ring, widely applied in 5G high-frequency copper-clad laminates, UV curable coatings and low-shrinkage 3D printing resins with low dielectric loss and high refractive index.
Products Specification
|
Product name |
HPPA/2-HYDROXY-3-PHENOXYPROPYL ACRYLATE |
|
CAS NO |
16969-10-1 |
|
ITEM NO |
M16969101 |
| Boiling point | 325.4℃ |
| Color intensity (APHA) | ≤150 |
| Refractive index | n₂₀/D = 1.528 |
| Density | 1.16 g/mL(25℃) |
| Water | ≤0.10% |
| Flash point | 88.9℃ |
|
Package |
5g/50g/100g/1kg/25kg |
|
Delivery |
2-3days |
|
Storage |
≤25℃ |
|
MSDS/COA |
connect us |
Products application
1. 5G high-frequency copper-clad laminate substrate resin, reducing dielectric loss
2. UV light-curable coatings and inks, enhancing adhesion and resistance to yellowing
3. Low-shrinkage 3D printing photosensitive resin
4. Optical high-refractive-index coating, fiber optic coating material
FAQ
FAQ
Q: Can I visit your factory?
A: Sure! Welcome anytime.
Q: How about the payment items?
A: L/C, D/P, T/T.
Q: Can you accept the inspection from a third party?
A: Yes. We have enough experience to cooperate with the inspection project.
Q: How long is the delivery time?
A: Usually, the shipment can be delivered within 10-15 days after the order is confirmed.
Q: Could COA and MSDS documents be provided for each batch?
A: For each batch, we can provide the complete set of COA and MSDS documents.
Q: Will there be any resin yellowing problem under the high-temperature and high-pressure bonding process?
A: Under normal copper-clad laminate high-temperature lamination conditions, it shows a slight yellowing. Overall, its temperature resistance and anti-yellowing properties are much better than those of ordinary hydroxy acrylate monomers.
Q: Could hydroxyl groups enhance the adhesion of the paint film to the plastic substrate?
A: Sure. The hydroxyl groups can anchor to the polar groups on the plastic surface, significantly enhancing the adhesion of the paint film.
Q: To what extent can the addition achieve a reduction in the curing shrinkage rate of the photosensitive resin?
A: It can effectively reduce the solidification shrinkage rate by approximately 30% to 45%, significantly reducing the warping deformation of the printed piece.
Q: Will it enhance the toughness and bending resistance of the printed product?
A: Sure. The phenolic flexible structure effectively enhances toughness and bending resistance, and is less prone to cracking.
Q: Could the modification with epoxy improve the moisture resistance and heat resistance properties?
A: Sure. The rigid structure of the benzene ring combined with the increased cross-linking density of the hydroxyl groups can significantly enhance the moisture resistance and boiling water resistance of the modified epoxy.
